Shelving and Storage Systems

CBF Industries offers complete storage solutions for everything from basic backroom storage to integrated warehouse applications. Basic systems are configured from posts, shelves and compression clips and are enhanced with bins, boxes, dividers and drawers to maximize available space and create efficient storage solutions.

Industrial Clip Shelving

Angle Post

Post material shall be 14 gauge, hot-rolled, pickled and oiled steel. Angle post shall be roll formed, the overall shape being that of an angle, the side leg which shall be 1-7/8", and the front leg which shall be 1". The 1-7/8" leg of the angle shall have a channel shaped rolled into it for added strength. Both legs shall be punched with 5/16" diameter holes on 1-1/2" centers for attaching shelves, backs, uprights and accessories. Rectangular slots 7/16" x 15/32" shall be punched in the 1-7/8" leg to accommodate shelf clips. Posts shall be longer by 1" than the designated length in feet. Available heights are 3'-1" through 16'-1". Angle posts are available in 1-1/2" height increments. Overall height of spliced posts will be 2" over the nominal full foot heights.

Beaded Post

Post material shall be 14 gauge, hot-rolled, pickled and oiled steel. Front face of beaded post 7/8". Overall side dimension of post 2-11/16". Post sides to be punched with 5/16" diameter holes on 1-1/2" centers for attaching shelves, side sheets and accessories. 7/16" x 15/32" rectangular slots shall be punched on 1-1/2" centers on both sides for attaching shelf clips. Posts shall be longer by 1" than the designated length in feet. Available heights are 3'-1" through 16'-1". Beaded posts are available in 1-1/2" height increments. Overall height of spliced posts will be 2" over the nominal full foot heights.
